38
ENG
ENGLISH
SPECIFICATIONS
Wireless LAN(AN-WF100) specification
(Depending on model)
Standard
IEEE802.11a/b/g/n
IEEE 802.11b/g/n in Indonesia
IEEE 802.11a/b/g in Russia and Tunisia
Host Interface USB 2.0
Frequency Range
2.400 to 2.483 GHz
5.150 to 5.250 GHz
5.725 to 5.850 GHz
Security 64/128 bit WEP, WPA, WPA2, TKIP, AES, WPS (PIN, PBC)
Sensitivity
802.11a: -72 dBm (54 Mbps)
802.11b: -84 dBm (11, 5.5, 2, 1 Mbps)
802.11g: -72 dBm (54 Mbps)
802.11n: -64 dBm (20 MHz) / -61 dBm (40 MHz)
Output Power
802.11a: 14 dBm (54 Mbps)
802.11b: 16.5 dBm (11, 5.5, 2, 1 Mbps)
802.11g: 14 dBm (54 Mbps)
802.11n: (2.4 GHz) 13.5 dBm (20 MHz) / 13.5 dBm (40 MHz)
802.11n: (5 GHz) 13.5 dBm (20 MHz) / 13.5 dBm (40 MHz)
Data rate
802.11a/g: 54 Mbps
802.11b: 11 Mbps
802.11n: 300 Mbps (40 MHz)
y Because band channel used by the country could be different, the user can not change or adjust the
operating frequency and this product is set for the regional frequency table.
y Because output power used by the country could be different, the user can not change or adjust the
operating output power and this product is set for the regional output power table.
