7-19
(2) CHECKOUT PROCEDURES FOR RELAY.
- PROBLEM (A) -
T.T. motor and oven lamp turn on without touching
START key when the door is closed.
Remove the mate connector of I/O
CON from the circuit board.
Does the unit still operate?
Replace the
circuit board
Replace
RELAY3
NO
NO
YES
YES
GOOD
Defective
RELAY3
- PROBLEM (B) -
T.T. motor and oven lamp turn on When the door is
closed and START key is touched.
Measure the voltage at pin NO.
4 of U01
Voltage reading: 0 Vdc
Replace the
circuit board
Defective
RELAY3 or poor
connection of
RELAY3
Replace
RELAY3 or correct
the connection.
YES
NO
NO
YES
GOOD
To Next Page
