16 INSTALLATION
Assembling the Left Refrigerator
Door
CAUTION
• Install the left refrigerator door after the right
door is installed.
1 Make sure that the plastic sleeve is inserted in
the bottom of the door. Install the refrigerator
door onto the middle hinge.
2 Fit the hinge a over the hinge lever latch b
and slot it into place. Rotate the lever
c
clockwise and fasten the hinge.
3 Connect all the wire harnesses d and the
ground screw
e.
4 Place the hinge cover f in place. Insert and
tighten the cover screw
g.
Removing the Freezer Drawer
Removing the lower freezer drawer in the same
way.
WARNING
• Use two or more people to remove and install
the refrigerator doors and freezer drawer.
• Be careful of sharp hinges on both sides of the
drawer.
• When you lay the drawer down, be careful not to
damage the floor.
• Do not sit or stand on the freezer drawer.
• To prevent accidents, keep children and pets
away from the drawer. Do not leave the drawer
open. If the Durabase
®
storage bin is removed
from the freezer drawer, there is sufficient space
for a small child or pet to crawl inside.
1 Pull the drawer open to full extension.
Removing the basket and ice bin from the
rails.
2 Remove the screws from the rails at both
ends.
3 Grip both sides of the drawer and pull it up to
remove it from the rails.
