WALL SECTION – DETAILED SIDE VIEW
FRAME AND BRICK VENEER INSTALLATION
Cord Set Connected
CAULK*
Sub-Base Connected
CAULK* STEEL LINTEL
RA B71 13-3/4" RA B77 13-7/8"
20-7/8" (RA B71) 21" (RA B77)
ROOM
CABINET
2" MIN.
M O U NTING SCREW S
BY INSTALLER
WALL CASE
OUTDOO R
GRILLE
CAULK*
CAULK*
1/4"
MIN.
POW ER SUPPLY
CONDUIT
W ALL RECEPTACLE
(BY O THERS)
FINISHED FLOO R
OR TOP OF
CA RPET
*Caulk around perimeter of wall case all four sides
w here it joins the building - Interior and Exterior.
CAULK* 1/4"
CAULK*
LINTEL
ROOM
CABINET
2" MIN.
M O U NTING SCREW S
BY INSTALLER
WALL CASE
OUTDOO R
GRILLE
SIDE CH A NNE L
3" MIN. 5" MAX.
1-5/16"
FINISHED FLOO R
OR TOP OF
CA RPET
SU B-BA SE
(RAK204)
CAULK*
POW ER SUPPLY CONDUIT
(ALTERN ATE ENTRY)
3-11/16"
*Caulk around perimeter of wall case all four sides w here it
joins the building - Interior and Exterior.
2-3/8"
