LG LP0817WSR User Manual

ENGLISH
19
INSTALLATION INSTRUCTIONS
INSTALLATION IN VERTICAL-SLIDING WINDOWS
Insert the diffuser into the opening in the vent
panel and slide it to lock it into place.
Align the tabs on the diffuser with the slots in the vent
panel. Insert the diffuser into the opening in the vent
panel and slide the diffuser to lock the tabs in place.
Insert the type C screw in the hole in the diffuser to
prevent the diffuser from sliding out of the vent
opening.
Slot
(1) Insert
(2) Slide
COV34636802 2018. 4. 23. 오후 5:11 페이지 19

LG LP0817WSR Specifications

General

Cooling Capacity	8, 000 BTU
Smart Diagnosis	Yes
Type	Portable Air Conditioner
Refrigerant	R32
Dehumidification	1.8 pints/hour
Control Type	Remote Control
Coverage Area	Up to 350 sq. ft.
