Parts List (LS-P0760CL/P0760HL, LS-P0820CL, LS-P0960CL/P0960HL)
Q/TY
LS-P0760CL LS-P0820CL LS-P0960CL LS-P0760HL LS-P0960HL
1 3300AR1008A PLATE INSTALLING 1 1 1 1 1
2 4930AR3015A HOLDER TUBE 1 1 1 1 1
3 4680AR2033 MOTOR, BLOWER 1E 1B 1D 1E 1D R
4 3141AR2032 CHASSIS ASM 1D 1D 1D 1D 1D R
5 3140AR3003 CHASSIS SIDE 2D 2D 2D 2D 2D
6 5835AR2034A BLOWER ASS'Y 1 1 1 1 1 R
7 3H02821A BEARING ASM 1 1 1 1 1 R
8 5421AR2035 EVAPORATOR ASS'Y 1D 1B 1D 1D 1H
9 5211AR2042A TUBE ASS'Y 1 1 1 1 1
10 6711AR1386 LCD REMOCON ASM 1C 1C 1C 1D 1D R
11 3A00375D SOCKET FLARE 1 1 1 1 1
12 4010AR3071A SOCKET FLARE 1 1 1 1 1
13 4781AR2263 CONTROLLER ASS'Y 1D 1D 1D
4781AR2097 1H
4781AR2360 1B
14 3H02255 POWER CORD ASS'Y 1U 1S 1U 1U 1T R
15 4994AR1007A CONTROL BOARD 1 1 1 1 1
16 6171AQ2147 POWER TRANS 1B 1B 1B 1B 1B R
17 6047AQ3029 DISPLAY P.C.B ASS'Y 1B 1B 1B 1B 1B R
18 6871AQ2155 MAIN P.C.B ASS'Y 1B 1B 1B 1E 1A R
19 3Q35099 THERMISTOR ASM 1A 1A 1A 1A 1A R
20 2H01803B STEP MOTOR ASM 1 1 1 1 1 R
21 5250AR2044A DRAIN HOSE ASS'Y 1 1 1 1 1
22 5991AR3142 VANE ASS'Y 1A 1A 1A 1A 1A
23 5009AR1080
DISCHARGE GRILLE ASM
1F 1F 1F 1F 1F
24 3530AR1006 INLET GRILLE 1H 1H 1H 1H 1H
25 3531AR1081 FRONT GRILLE ASS'Y 1Q 1Q 1Q 1R 1R R
26 5230AR2003A AIR FILTER 2 2 2 2 2 R
27 3H01487A SH CAPACITOR 1 1 1 1 1
28 4H03048A PILLAR TERMINAL 1 1 1 1 1
29 4933AR3352 CONNECTOR ASS'Y 1A 1A 1A 1A 1A
30 4933AR3353 CONNECTOR ASS'Y 1A 1A 1A 1B 1B
31 4H03048 PILLAR TERMINAL 1A 1A 1A 1C 1C
32 3700AR3072B STEEL NET 1 1 1 1 1
NO PART NO. PART NAME
REMARKS
ƒ¡71ƒ¡
To Next Page
