Parts List (LS-P0760CL/P0960CL, LS-S0960CL/S1260CL)
Q'TY
LS-P0760CL LS-P0960CL LS-S0960CL LS-S1260CL
1 2H02435B BASE PAN WELD ASM 1 1 1 1
2 1H00838A MOUNT, MOTOR 1 1 1 1
3 1H00853 MOTOR, FAN 1D 1D 1D 1D R
4 1H00643A FAN 1 1 1 1 R
4-1 1WPA0600014 PLAIN WASHER 1 1 1 1
4-2 4H02861A FAN NUT 1 1 1 1
5 2H02383B SUPPORT, VALVE 1 1 1 1
6 5403AR2046 CONDENSOR ASM 1A 1A 1A 1A
7 5417AR2256 COMPRESSOR 1A R
1H00408 1M 1N 1M
8 4H00982A ANTI-VIBRATION BUSH 3 3 3 3
9 1NHA0801206 HEXAGON NUTS 3 3 3 3
10 4H00972D WASHER 3 3 3
4H01811C 3
12 2H02479 SERVICE VALVE(1/4") 1B 1B 1B 1B R
13 2H01890 SERVICE VALVE(1/2") 1H 1H R
2A00393 SERVICE VALVE(3/8") 1F 1F
14 6750-CL005A OVER LOAD PROTECTOR 1 R
6750-CL013A 1 1 1
15 5300-CL101A O.L.P SPRING 1 1 1 1
16 4781AR2098 CONTROL PANEL ASM 1D 1D 1A 1A
17 4H01017A CLAMP, CAPACITOR 1 1 1 1
18 2A00986 SH CAPACITOR 1Q 1Q 1Q R
2HO1451 1P
19 4H03048 PILLAR TERMINAL 1A 1A 1A 1A R
20 3550-CL001 TERMINAL COVER 1D 1D 1D 1D
21 4H00947A NUT, TERMINAL COVER 1 1 1 1
22 1H00836B REAR PANEL 1 1 1 1
24 2H02448 CONTROL COVER ASM 1D 1D 1D 1D
25 3721AR2103B PANEL ASS'Y, FRONT 1 1 1 1
26 4H01050A BAND CORD 1 1 1 1
27 3H03714 TOP COVER ASM 1B 1B 1B 1B
28 1H00839A CONTROL PANEL 1 1 1 1
29 3H03168A HANDLE 1 1 1 1
