13
Ch2. Locations
Rear view
LAN connector
S-VIDEO connector
Modem connector AC connector
Express Card eject button
IEEE1394 connector4-in-1 Card slot
Fan louvers
VGA connector
Express Card slot
PC Card eject button
Left view
Parallel connector PC Card slot
USB connector
Right view
Emergency eject hole
USB connector
Line-in connector
Optical Disk Drive
Headphone connector
Security key hole
MIC connector ODD eject button
Security key hole (Kensington Lock)
User can attach a separately purchased chain lock into the security keyhole and connect it to a fixed object
to prevent a notebook theft
Emergency eject hole
Insert a thin and hard pin into this hole, and you can open the disc tray manually.
