6
15.0 EXPLODED VIEW
Location LG P/N SPECIFICATION REMARKS
HFL06 3111B0TS24A Case Assy, Front 15.0"
HFL13 4850BM4029A Cushion, rubber-upper
HFL14 4826BZ4003B Cushion, rubber-middle
HFL15 4850BM4030A Cushion, rubber-lower
HFL17 3850BB3042A Label, front brand name label
To Next Page
