LG LS70 - Page 86

15.0 EXPLODED VIEW
15
Location LG P/N SPECIFICATION REMARKS
HFD02 5022BZ9023A TOUCH PWB 79.7*47.7 HUNTER WIDE WITH SCROLL FUNCTION
SYNAPTICS TM41PUZ307-1
HFD03 3551B09756A HUNTER-FULL 15 INCH SPEAKER TOTAL ASSY
HFD04 6871BH830A1 HUNTER-FULL 15 INCH WIMTEC 2 LAYERS 1.0 PP TOUCH PAD SUB B/D ASSY
HFD05 6850B12005A UL20696 12P AWM 80C VW-1 L75MM 0.5MM PITCH KFC H154W(TOUCH PAD)
HFD06 4940BM3221A HUNTER-WIDE 15.4 INCH PCABS KBD DECK BUTTON, TOUCHPAD
HFM22 1SZZBA4017A screw M2.0 * L3.0
