LG LSEL6335D User Manual

63MAINTENANCE
ENGLISH
a Hinge arm
b Hinge lock
5 Close the oven door.
Removing/Assembling Drawers
Removing Drawers
CAUTION
• Disconnect the electrical power to the range at
the main fuse or circuit breaker panel. Failure to
do so can result in severe personal injury, death,
or electrical shock.
Most cleaning can be done with the drawer in
place; however, the drawer may be removed if
further cleaning is needed. Use warm water to
thoroughly clean.
1 Fully open the drawer.
2 Locate the glide lever on each side of the
drawer. Push down on the left glide lever and
pull up on the right glide lever.
a Lever
b Push down with finger
c Pull up with finger
3 Pull the drawer away from the range.
Assembling Drawers
1 Pull the bearing glides to the front of the
chassis glide.
2 Align the glide on each side of the drawer with
the glide slots on the range.
3 Push the drawer into the range until levers
click (approximately 2 inches).
4 Pull the drawer open again to seat the
bearing glides into position.
Removing/Assembling the Vent
Trim
Removing the Vent Trim
1 Using a screwdriver, remove the two screws
holding the vent trim in place.
2 Move the vent trim in the indicated direction
approximately 1/4".
3 Lift the vent trim.
us_main.book.book Page 63 Wednesday, February 3, 2021 9:14 AM

LG LSEL6335D Specifications

General

Style	storage (w/ handle)
Color	black stainless steel
Main Capacity	6.3 cu. ft.
Options	glass touch (smoothtouch™)
Cooking Programs	bake, conv. bake, conv. roast, broil high, broil low, warm, proof, frozen meal, air fry, slow cook, easyclean, selfclean
Temperature Probe	no
Convection	yes
Number of Burners	5
Number of Racks	3
Control Type	knobs; touch sensor; front tilt-control knobs; glass touch
Interior Light	yes
Remote Control	yes
Smart Home	smartthinq, google assistant, amazon alexa
Wi-Fi	yes
Power Consumption	4, 200
Fuel	electric
Voltage	240/208 volts
Current	40

Weight and Dimensions

Depth	29 3/32 inch
Height	36 1/2 inch
Width	30 inch
