3. Loosely assemble the sill support using the parts
in
Figure 4.
4. Select the position that will place the sill
support near the outer most point on sill
(See
Figure
4)
Be careful when you install the cabinet
(Frame Guides
are broken easily).
5. Attach the sill support to the cabinet track hole in
relation to the selected position using
2 Type A screws in each support (See Figure 5).
6. The cabinet should be installed with a very slight
tilt (about
1
/2") downward toward the outside
(See Figure 6).
Adjust the bolt and the nut of Sill Support for
balancing the cabinet.
7. Attach the cabinet to the window stool by
driving the screws (Type B) through the front
angle into window stool (5/8").
8. Pull each Frame Curtain properly to each win-
dow sash track, and repeat step 2.
9. Attach each Frame Curtain to the window sash
by using screws (Type C).
(See
Figure
7)
To Next Page
