Controlling the Multiple Product
RS-232C
8
Transmission / Receiving Protocol
09. OSD Select(Command : l)
To control OSD on/off to the set.
Transmission
[k][l][ ][Set ID][ ][Data][Cr]
Data 0 : OSD Off 1 : OSD On
Acknowledgement
[l][ ][Set ID][ ][OK][Data][x]
Data 0 : OSD Off 1 : OSD On
10. Remote On/Off (Command : m)
Lock the buttons at the rear side of the monitor and the button at the remote control.
Transmission
[k][m][ ][Set ID][ ][Data][Cr]
Data 0 : Off 1 : On
Acknowledgement
[m][ ][Set ID][ ][OK][Data][x]
Data 0 : Off 1 : On
▲
▲
11. Balance (Command : t)
To adjust the sound balance.
Transmission
[k][t][ ][Set ID][ ][Data][Cr]
Data Min : 00H ~ Max : 64H
32H : Center 00H : Left 64H : Right
Acknowledgement
[t][ ][Set ID][ ][OK][Data][x]
32H : Center 00H : Left 64H : Right
▲
