LG M4214C User Guide

22
Selecting the options
Tile mode
Tile mode and choose Tile alignment and set the ID of the current product to set
location.
* Only after pressing the SET button the
adjustments made to the settings will be saved.
Language
Child lock
ISM Method
Set ID
Tile Mode
Power Indicator
Tile Mode
Tile ID
H-Size
V-Size
H-Position
V-Position
Reset
Off
Natural
Off
0
0
0
To set
Demo
It is used to enlarge the screen and
also used with several products to
view screen.
• To use this function
- Must be displayed with various other products.
- Must be in a function that can be connected to RS-232C or RGB Out
• Tile Mode
- Tile mode : row x column ( r = 1, 2, 3, 4 c = 1, 2, 3, 4)
- 4 x 4 available.
- Configuration of an integration screen is also available as well as
configuration of One by one Display.
ID 1
ID 2
ID 3
ID 4
- Tile mode (product 1 ~ 4) : r(2) x c(2)
row
column
Selecting and Adjusting the Screen
