1414
Connect the video/audio cable as shown in the below gure and then connect the power
cord (See page 7).
RCA-PC
Audio Cable
(not included)
Product
VCR/DVD/Set-top Box
HDMI to DVI
Signal Cable
(not included)
VCR/DVD/Set-top Box
Product
Select an input signal.
Press the INPUT button on the remote control to select the input signal.
Or, press the SOURCE button on the back of the product.
HDMI Signal Cable
(not included)
Connecting to External Devices
When connecting with a HDMI to DVI signal input cable.
When connecting with a HDMI signal input cable.
• Select HDMI/DVI
- HDMI Supports High Denition input and HDCP (High-bandwidth Digital Content Protec-
tion). Some devices require HDCP in order to display HD signals.
Note : Dolby Digital is not supported.
Input
AV
Component
RGB PC
HDMI/DVI
▲▼
INPUT SET
▼▲
HDMI Input (480p/576p/720p/1080i/1080p)
SOURCE
AUTO/SET
▼▲
To Next Page
