LG MULTI V WATER IV ARWN LAS4 Series Installation Manual

Outside units Information
12 Outside Unit
Unit 4 Unit
System Capacity (HP) 62 64 66
Model
Combination Unit
ARWN620LAS4 ARWN640LAS4 ARWN660LAS4
Independent Unit
ARWN200LAS4
ARWN200LAS4
ARWN120LAS4
ARWN100LAS4
ARWN200LAS4
ARWN200LAS4
ARWN120LAS4
ARWN120LAS4
ARWN200LAS4
ARWN200LAS4
ARWN140LAS4
ARWN120LAS4
Refrigerant Precharged Amount kg
3.0 + 3.0 + 3.5 + 3.4 3.0 + 3.0 + 3.5 + 3.5 3.0 + 3.0 + 5.8 + 3.5
Maximum Connectable Number of Indoor Units 64 64 64
Net Weight
kg
(140 x 2) + (125 x 2) (140 x 2) + (125 x 2) (140 x 2) + (127 x 1) + (125 x 1)
lbs (309 x 2) + (276 x 2) (309 x 2) + (276 x 2) (309 x 2) + (280 x 1) + (276 x 1)
Dimensions(WxHxD)
mm
(755 × 997 × 500) x 4 (755 × 997 × 500) x 4 (755 × 997 × 500) x 4
inch
(29-23/32 x 39-1/4 x 19-11/16) x 4 (29-23/32 x 39-1/4 x 19-11/16) x 4 (29-23/32 x 39-1/4 x 19-11/16) x 4
Refrigerant
Connecting Pipes
Liquid mm(inch)
22.2(7/8) 22.2(7/8) 22.2(7/8)
Gas mm(inch)
44.5(1-3/4) 44.5(1-3/4) 53.98(2-1/8)
Water Connecting
Pipes
Inlet mm
PT 40 + PT 40 + PT 40 + PT32 PT 40 + PT 40 + PT 40 + PT32 PT 40 + PT 40 + PT 40 + PT32
Outlet mm PT 40 + PT 40 + PT 40 + PT32 PT 40 + PT 40 + PT 40 + PT32 PT 40 + PT 40 + PT 40 + PT32
Drain Outlet mm 20 20 20
Temp. range of
Circulation water
Cooling
10°C ~ 45°C(50°F ~ 113°F) 10°C ~ 45°C(50°F ~ 114°F) 10°C ~ 45°C(50°F ~ 115°F)
Heating -5°C ~ 45°C(23°F ~ 113°F) -5°C ~ 45°C(23°F ~ 114°F) -5°C ~ 45°C(23°F ~ 115°F)
Unit 4 Unit
System Capacity (HP) 68 70 72
Model
Combination Unit
ARWN680LAS4 ARWN700LAS4 ARWN720LAS4
Independent Unit
ARWN200LAS4
ARWN200LAS4
ARWN140LAS4
ARWN140LAS4
ARWN200LAS4
ARWN200LAS4
ARWN160LAS4
ARWN140LAS4
ARWN200LAS4
ARWN200LAS4
ARWN180LAS4
ARWN140LAS4
Refrigerant Precharged Amount kg
3.0 + 3.0 + 5.8 + 5.8 3.0 + 3.0 + 3.0 + 5.8 3.0 + 3.0 + 3.0 + 5.8
Maximum Connectable Number of Indoor Units 64 64 64
Net Weight
kg
(140 x 2) + (127 x 2) (140 x 3) + (127 x 1) (140 x 3) + (127 x 1)
lbs
(309 x 2) + (280 x 2) (309 x 3) + (280 x 1) (309 x 3) + (280 x 1)
Dimensions(WxHxD)
mm
(755 × 997 × 500) x 4 (755 × 997 × 500) x 4 (755 × 997 × 500) x 4
inch
(29-23/32 x 39-1/4 x 19-11/16) x 4 (29-23/32 x 39-1/4 x 19-11/16) x 4 (29-23/32 x 39-1/4 x 19-11/16) x 4
Refrigerant
Connecting Pipes
Liquid mm(inch)
22.2(7/8) 22.2(7/8) 22.2(7/8)
Gas mm(inch)
53.98(2-1/8) 53.98(2-1/8) 53.98(2-1/8)
Water Connecting
Pipes
Inlet mm
PT 40 + PT 40 + PT 40 + PT40 PT 40 + PT 40 + PT 40 + PT40 PT 40 + PT 40 + PT 40 + PT40
Outlet mm PT 40 + PT 40 + PT 40 + PT40 PT 40 + PT 40 + PT 40 + PT40 PT 40 + PT 40 + PT 40 + PT40
Drain Outlet mm 20 20 20
Temp. range of
Circulation water
Cooling
10°C ~ 45°C(50°F ~ 116°F) 10°C ~ 45°C(50°F ~ 117°F) 10°C ~ 45°C(50°F ~ 118°F)
Heating -5°C ~ 45°C(23°F ~ 116°F) -5°C ~ 45°C(23°F ~ 117°F) -5°C ~ 45°C(23°F ~ 118°F)
