LG NP7550 - Page 70

70
15. LGH791, LGH791F
Rear Cover Remove
1) All Screw 10ea remove
(Red side 9Point 3.5mm)
Screw should be separated
2) Right bottom side Main Ant. first
3) Right side Rear Cover first
Main Ant. remove
(Remove procedure : A  B)
A-1
A-2
hook
A
B
F
C
D
E
C
hook
Rear Cover remove
(Remove procedure : C  D  E  F)
