LG OLED65C1PUB User Manual

11
ENGENGLISH
11
EXTERNAL CONTROL DEVICE SETUP
2. Tune to the BS (ISDB-BS) channel 30.
Set ID = All = 00
Data 00 = Don’t know Physical = 00
Data 01 & 02 = Major is 30 = 00 1E
Data 03 & 04 = Don’t Care = 00 00
Data 05 = Digital BS TV = 07
Total = ma 00 00 00 1E 00 00 07
* This feature is varied based on the model.
Ack [a][ ][Set ID][ ][OK][Data 00][Data 01]
[Data 02][Data 03][Data 04][Data 05]
[x][a][ ][Set ID][ ][NG][Data 00][x]
21. Channel(Programme) Add/Del(Skip)
(Command: m b)
► To skip current channel(programme) for next time.
Transmission [m][b][ ][Set ID][ ][Data][Cr]
Data 00 : Del(ATSC,ISDB)/Skip(DVB) 01 : Add
Ack [b][ ][Set ID][ ][OK/NG][Data][x]
* Set the saved channel status to del(ATSC, ISDB)/
skip(DVB) or add.
22. Key (Command: m c)
► To send IR remote key code.
Transmission [m][c][ ][Set ID][ ][Data][Cr]
Data Key code - p.2.
Ack [c][ ][Set ID][ ][OK/NG][Data][x]
23. Control Backlight (Command: m g)
• For LCD TV / LED TV
► To control the backlight.
Transmission [m][g][ ][Set ID][ ][Data][Cr]
Data Min : 00 to Max : 64
Ack [g][ ][Set ID][ ][OK/NG][Data][x]
Control Panel Light (Command: m g)
• For Plasma TV
► To control the panel light.
Transmission [m][g][ ][Set ID][ ][Data][Cr]
Data Min : 00 to Max : 64
Ack [g][ ][Set ID][ ][OK/NG][Data][x]
24. Input select (Command: x b)
(Main Picture Input)
► To select input source for main picture.
Transmission [x][b][ ][Set ID][ ][Data][Cr]
Data
00 : DTV
02 : Satellite DTV
ISDB-BS (Japan)
03 : ISDB-CS1 (Japan)
04 : ISDB-CS2 (Japan)
11 : CATV
01 : CADTV
10 : ATV
20 : AV or AV1 21 : AV2
40 : Component1
60 : RGB
41 : Component2
90 : HDMI1
92 : HDMI3
91 : HDMI2
93 : HDMI4
Ack [b][ ][Set ID][ ][OK/NG][Data][x]
* This function depends on model and signal.
25. 3D(Command: x t) (only 3D models)
(Depending on model)
► To change 3D mode for TV.
Transmission [x][t][ ][Set ID][ ][Data 00][ ][Data 01]
[ ][Data 02][ ][Data 03][Cr]
* (Depending on model)
Data Structure
[Data 00] 00 : 3D On
01 : 3D Off
02 : 3D to 2D
03 : 2D to 3D
[Data 01] 00 : Top and Bottom
01 : Side by Side
02 : Check Board
03 : Frame Sequential
04 : Column interleaving
05 : Row interleaving
[Data 02] 00 : Right to Left
01 : Left to Right
[Data 03] 3D Effect(3D Depth): Min : 00 - Max : 14
(*transmit by Hexadecimal code)

LG OLED65C1PUB Specifications

General

Screen shape	Flat
Display diagonal	65 \
Display brightness	- cd/m²
Display technology	OLED
Native aspect ratio	16:9
Native refresh rate	120 Hz
Contrast ratio (typical)	-
Display diagonal (metric)	165.1 cm
Motion interpolation technology	OLED Motion Pro
Tuner type	Analog & digital
Digital signal format system	ATSC
Smart modes	Cinema, Energy saving, Game, Sports, Standard, Vivid
App distribution platform	LG Apps
Operating system installed	Web OS
Sound modes	Dolby Audio
RMS rated power	40 W
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Stand type	Connected stand
Product color	Gray
Panel mounting interface	300 x 200 mm
Game features	Auto Low Latency Mode (ALLM), Variable Refresh Rate (VRR)
Subtitle formats supported	ASS, PSB, SMI, SRT, SSA, SUB, TXT
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
HDMI version	2.2
PC in (D-Sub)	No
HDMI ports quantity	4
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	SimpLink
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	130 W
Cables included	AC
Package depth	205.74 mm
Package width	1676.4 mm
Package height	949.96 mm
Package weight	41186.19 g
Quantity per box	1 pc(s)

Weight and Dimensions

Stand width	998.22 mm
Depth (with stand)	251.46 mm
Width (with stand)	1447.8 mm
Height (with stand)	861.06 mm
Weight (with stand)	32613.29 g
Depth (without stand)	45.72 mm
Height (without stand)	830.58 mm
Weight (without stand)	23995.04 g
