LG OLED65C8PUA Service Manual

- 2 -
Copyright © LG Electronics Inc. All rights reserved.
Only for training and service purposes.
CONTENTS
CONTENTS .............................................................................................. 2
SAFETY PRECAUTIONS ........................................................................ 3
SERVICING PRECAUTIONS ................................................................... 4
SPECIFICATION .......................................................................................6
SOFTWARE UPDATE .............................................................................. 9
BLOCK DIAGRAM ................................................................................. 10
EXPLODED VIEW .................................................................................. 16
DISASSEMBLY GUIDE .......................................................................... 17
TROUBLE SHOOTING GUIDE ................................................ APPENDIX

LG OLED65C8PUA Specifications

General

Display diagonal	65 \
Progressive scan	Yes
Display technology	OLED
Video apps	YouTube
Operating system installed	Web OS
RMS rated power	40 W
Number of speakers	2.2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
HDMI ports quantity	4
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth (with stand)	9.1 mm
Width (with stand)	57 mm
Height (with stand)	34.7 mm
Weight (with stand)	2540 g
Depth (without stand)	1.8 mm
Height (without stand)	32.7 mm
Weight (without stand)	2100 g
