LG OLED65C8PUA Service Manual

- 6 -
Copyright © LG Electronics Inc. All rights reserved.
Only for training and service purposes.
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement .
1. Application range
This specification is applied to the OLED TV used EA81E
chassis.
2. Test condition
Each part is tested as below without special appointment.
(1) Temperature : 25 ºC ± 5 ºC(77 ± 9 ºF) , CST : 40 ºC ± 5 ºC
(2) Relative Humidity: 65 % ± 10 %
(3) Power Voltage
: Standard input voltage (AC 100-240 V~, 50/60 Hz)
* Standard Voltage of each products is marked by models.
(4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
(5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
(1) Performance: LGE TV test method followed
(2) Demanded other specification
- Safety : UL, CSA, CE, IEC specification
- EMC : FCC, ICES, CE, IEC specification
4. General Specification
No Item Specication Remark
1 Market North America
2 Broadcasting system ATSC / NTSC-M, 64 & 256 QAM
3 Available Channel VHF : 02~13
UHF : 14~69
DTV : 02-69
CATV : 01~135
CADTV : 01~135
4 Receiving system Digital : ATSC, 64 & 256 QAM
Analog : NTSC-M
5 Video Input NTSC-M Rear gender(1EA)
6 HDMI Input HDMI 1 PC / DTV format B, C, E : Side, Support 6Gbps
W : Rear, Support 6Gbps
HDMI 2 PC / DTV format B, C, E : Side, Support 6Gbps, Support ARC
W : Rear, Support 6Gbps, Support ARC
HDMI 3 PC / DTV format B, C, E : Side, Support 6Gbps
W : Rear, Support 6Gbps
HDMI 4 PC / DTV format Side, Support 6Gbps
7 Audio Input AV Audio / DVI Audio Rear(AV Gender), Except Korea model
AV and DVI use same jack
8 SPDIF out(1EA) Optical Audio out Rear (1EA),
9 USB Input(3EA) EMF, DivX HD, For SVC (download) JPEG, MP3, DivX HD
B, C, E : Side(1EA), Rear(2EA)
W : Rear(3EA)

LG OLED65C8PUA Specifications

General

Display diagonal	65 \
Progressive scan	Yes
Display technology	OLED
Video apps	YouTube
Operating system installed	Web OS
RMS rated power	40 W
Number of speakers	2.2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
HDMI ports quantity	4
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth (with stand)	9.1 mm
Width (with stand)	57 mm
Height (with stand)	34.7 mm
Weight (with stand)	2540 g
Depth (without stand)	1.8 mm
Height (without stand)	32.7 mm
Weight (without stand)	2100 g
