LG OLED65C9PLA User Manual

10
ENGLISH
To use the button, press and hold for more than 1 second.
(POWER) Turns the TV on or o.
/ You can turn your set-top box on or o by adding the set-
top box to the universal remote control for your TV.
Number buttons Enters numbers.
Accesses the [QUICK HELP].
(DASH) Inserts a between numbers such as 2-1 and 2-2.
/ Accesses the saved programmes list.
(More Actions) Displays more remote control functions.
Edits QUICK ACCESS.
- QUICK ACCESS is a feature that allows you to enter a specied app
or Live TV directly by pressing and holding the number buttons.
Audio descriptions function will be enabled.
Adjusts the volume level.
(MUTE) Mutes all sounds.
(MUTE) Accesses the [Accessibility] menu.
Scrolls through the saved programmes.
(Voice recognition) Network connection is required to use the
voice recognition function. Once the voice display bar is activated on
the TV screen, press and hold the button and speak your command
out loud.
(HOME) Accesses the Home menu.
(HOME) Shows the previous history.
(Q. Settings) Accesses the Quick Settings.
(Q. Settings) Displays the [All Settings] menu.
Wheel (OK) Press the center of button to select a menu. You
can change programmes by using button.
(up/down/left/right) Press the up, down, left or right
button to scroll the menu. If you press buttons while the
pointer is in use, the pointer will disappear from the screen and Magic
Remote will operate like a general remote control. To display the
pointer on the screen again, shake Magic Remote to the left and right.
/ Returns to the previous level.
/ Clears on-screen displays and returns to last input
viewing.
/ Shows programme guide.
Using Magic Remote
Control
The descriptions in this manual are based on the buttons on the remote
control. Please read this manual carefully and use the TV correctly.
When the message [Magic Remote battery is low. Please change the
battery.] is displayed, replace the battery.
To replace batteries, open the battery cover, replace batteries (1.5 V AA)
matching the and ends to the label inside the compartment,
and close the battery cover. Be sure to point the magic remote toward
the remote control sensor on the TV. To remove the batteries, perform
the installation actions in reverse.
1
1
1
1
1
(Some buttons and services may not be provided depending on models
or regions.)

LG OLED65C9PLA Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	65 \
Display brightness	- cd/m²
Display technology	OLED
Native aspect ratio	16:9
Display diagonal (metric)	164 cm
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	-
3D	No
App store	LG Content Store
Battery type	AA
Google applications	Google Home
Annual energy consumption	190 kWh
Number of batteries supported	2
Remote control input capabilities	Pointing, Voice recognition
RF connector type	F, IEC
HDMI ports quantity	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Digital audio optical out	1
Common interface Plus (CI+) version	1.4
Tuner type	Digital
Analog signal format system	Not supported
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Music apps	Spotify
Video apps	Amazon Prime Video, Catch-up TV, Mediaset Play, Netflix, YouTube
Operating system installed	Web OS
Power consumption (standby)	0.5 W
Power consumption (typical)	137 W
Audio decoders	DTS, Dolby Atmos, Dolby Digital
RMS rated power	40 W
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Product color	Black
Panel mounting interface	300 x 200 mm
Audio formats supported	AAC, AC3, AC4, DTS, EAC3, HE-AAC, MP2, MP3, PCM, WMA, apt-X
Video formats supported	H.265, HEVC
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10)
Cables included	AC
Remote control type	MR19
Package type	Box
Package depth	207 mm
Package width	1677 mm
Package height	950 mm
Package weight	41200 g

Weight and Dimensions

Depth (with stand)	251 mm
Height (with stand)	862 mm
Weight (with stand)	33900 g
Depth (without stand)	46.9 mm
Width (without stand)	1449 mm
Height (without stand)	830 mm
Weight (without stand)	25200 g
