LG OLED65G6P-U - Page 41

(13-1) Disconnect the connector 2EA of Power Cables.
(13-2) Disconnect the connector 2EA of VX1 Cables.
(13-3) Separate the Hinge Cable Assy and then put down it on the table.
(※ If you change these cables, refer to the extra guide at final pages.)
13-2
13-1
13-3
OLED65G6 Disassembly Guide
Copyright © 2016 LG Electronics Inc. All rights reserved.
Only for training and service purposes
