(6-1) Connect the Power Cable Connector 2EA from the Bottom of Hinge Cable Assy.
(6-2) Connect the VX1 Cable Connector 2EA from the Bottom of Hinge Cable Assy.
6-2
6-1
OLED65G6 Re-assembly Guide
