- 15 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
400
200
570
120
500
521
571
920
810
831
830
510
121
951
AW1
710
530
900
A10
AR2
ARC2
540
AE1
AE2
Depending on model
AB4
EXPLODED VIEW
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These
parts are identified by in the EXPLODED VIEW.
It is essential that these special safety parts should be replaced with the same components as
recommended in this manual to prevent Shock, Fire, or other Hazards.
Do not modify the original design without permission of manufacturer.
IMPORTANT SAFETY NOTICE
To Next Page
