- 23 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
10. Remove screw 7 EA, disassemble stand guide and stand fixer.
11. Remove screw 4 EA, disassemble VESA Bracket
1
1
1
1
Screw : 4 EA
1
1
1
1
1
1
Screw : 7 EA
1
1
1
