5.2.4. EDID DATA
▪ Reference
- HDMI1 ~ HDMI3
- In the data of EDID, bellows may be different by Input mode
ⓐ Product ID
ⓑ Serial No: Controlled on production line.
ⓒ Month, Year: Controlled on production line:
ex) Monthly : ‘01’ -> ‘01’
Year : ‘2016’ -> ‘1A'
ⓓ Model Name(Hex): LGTV
ⓔ Checksum(LG TV): Changeable by total EDID data.
ⓕ Vendor Specific(HDMI)
5.2.4.1. EDID
▪ DTS
# HDMI1 (C/S: 0x9F, 0x65) – HDMI UHD Deep On CaseEDID
# HDMI1 (C/S: 0x9F, 0x8B) – HDMI UHD Deep Off Case
# HDMI2 (C/S: 0x9F, 0x55) – HDMI UHD Deep On Case
# HDMI2 (C/S: 0x9F, 0x7B) – HDMI UHD Deep Off Case
EDID Block 0, Bytes 0-127
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
10 01 1A 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80
30 01 01 01 01 01 01 08 E8 00 30 F2 70 5A 80 B0 58
40 8A 00 40 84 63 00 00 1E 02 3A 80 18 71 38 2D 40
50 58 2C 45 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
60 3E 1E 88 3C 00 0A 20 20 20 20 20 20 00 00 00 FC
70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 9F
EDID Block 1, Bytes 128-255
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 02 03 49 F1 50 61 10 04 05 03 02 20 22 01 5D 5E
10 5F 66 62 63 64 29 3D 06 C0 15 07 50 09 57 07 75
20 03 0C 00 10 00 B8 3C 20 C0 87 01 02 03 04 01 40
30 01 FC 18 10 16 67 D8 5D C4 01 78 80 03 E3 05 C0
40 00 E3 0F 01 10 E3 06 07 01 01 1D 80 18 71 1C 16
50 20 58 2C 25 00 40 84 63 00 00 9E 66 21 50 B0 51
60 00 1B 30 40 70 36 00 40 84 63 00 00 1E 00 00 00
70 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 65
0 1 2 3 4 5 6 7 8 9 A B C D E F
00 00 FF FF FF FF FF FF 00 1E 6D a b
01 c 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
02 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80
03 01 01 01 01 01 01 08 E8 00 30 F2 70 5A 80 B0 58
04 8A 00 40 84 63 00 00 1E 02 3A 80 18 71 38 2D 40
05 58 2C 45 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
06 3E 1E 88 3C 00 0A 20 20 20 20 20 20 d
07 d 01 e1
00 02 03 49 F1 50 61 10 04 05 03 02 20 22 01 5D 5E
01 5F 66 62 63 64 29 3D 06 C0 15 f
02 f
03 f 10 16 67 D8 5D C4 01 78 80 03 E3 05 C0
04 00 E3 0F 01 10 E3 06 07 01 01 1D 80 18 71 1C 16
05 20 58 2C 25 00 40 84 63 00 00 9E 66 21 50 B0 51
06 00 1B 30 40 70 36 00 40 84 63 00 00 1E 00 00 00
07 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 e2
EDID Block 0, Bytes 0-127
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
10 01 1A 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80
30 01 01 01 01 01 01 08 E8 00 30 F2 70 5A 80 B0 58
40 8A 00 40 84 63 00 00 1E 02 3A 80 18 71 38 2D 40
50 58 2C 45 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
60 3E 1E 88 3C 00 0A 20 20 20 20 20 20 00 00 00 FC
70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 9F
EDID Block 1, Bytes 128-255
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 02 03 3B F1 4E 5D 10 04 05 03 02 20 22 01 5E 5F
10 62 63 64 29 3D 06 C0 15 07 50 09 57 07 75 03 0C
20 00 10 00 B8 3C 20 C0 87 01 02 03 04 01 40 01 FC
30 18 10 16 E3 0E 61 66 E3 06 07 01 01 1D 80 18 71
40 1C 16 20 58 2C 25 00 40 84 63 00 00 9E 66 21 50
50 B0 51 00 1B 30 40 70 36 00 40 84 63 00 00 1E 00
60 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
70 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 8B
EDID Block 0, Bytes 0-127
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
10 01 1A 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80
30 01 01 01 01 01 01 08 E8 00 30 F2 70 5A 80 B0 58
40 8A 00 40 84 63 00 00 1E 02 3A 80 18 71 38 2D 40
50 58 2C 45 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
60 3E 1E 88 3C 00 0A 20 20 20 20 20 20 00 00 00 FC
70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 9F
EDID Block 1, Bytes 128-255
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 02 03 49 F1 50 61 10 04 05 03 02 20 22 01 5D 5E
10 5F 66 62 63 64 29 3D 06 C0 15 07 50 09 57 07 75
20 03 0C 00 20 00 B8 3C 20 C0 87 01 02 03 04 01 40
30 01 FC 18 10 16 67 D8 5D C4 01 78 80 03 E3 05 C0
40 00 E3 0F 01 10 E3 06 07 01 01 1D 80 18 71 1C 16
50 20 58 2C 25 00 40 84 63 00 00 9E 66 21 50 B0 51
60 00 1B 30 40 70 36 00 40 84 63 00 00 1E 00 00 00
70 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 55
EDID Block 0, Bytes 0-127
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01
10 01 1A 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26
20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80
30 01 01 01 01 01 01 08 E8 00 30 F2 70 5A 80 B0 58
40 8A 00 40 84 63 00 00 1E 02 3A 80 18 71 38 2D 40
50 58 2C 45 00 40 84 63 00 00 1E 00 00 00 FD 00 3A
60 3E 1E 88 3C 00 0A 20 20 20 20 20 20 00 00 00 FC
70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 9F
EDID Block 1, Bytes 128-255
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 02 03 3B F1 4E 5D 10 04 05 03 02 20 22 01 5E 5F
10 62 63 64 29 3D 06 C0 15 07 50 09 57 07 75 03 0C
20 00 20 00 B8 3C 20 C0 87 01 02 03 04 01 40 01 FC
30 18 10 16 E3 0E 61 66 E3 06 07 01 01 1D 80 18 71
40 1C 16 20 58 2C 25 00 40 84 63 00 00 9E 66 21 50
50 B0 51 00 1B 30 40 70 36 00 40 84 63 00 00 1E 00
60 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
70 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 7B
