OLED77G6 Disassembly Guide
(9-1) Grip the third lane at the front side and grip the first lane at the rear side like the picture,
and then lift up having a little power, you can separate the latches middle area of [Cover Ass’y, AV BOX].
(9-2) Do the same working at Opposite side to separate middle area of [Cover Ass’y, AV BOX].
9-1 9-2
Latch separation
You have to separate these
inside latches.
9-2
9-1
Latch separation
Copyright © 2016 LG Electronics Inc. All rights reserved.
Only for training and service purposes
