LG OLED77G6P - Page 52

4-1
Main PCB
4-2
Sub PCB
4-1
4-1
4-1
4-1
4-2
4-2
4-2
4-2
4-2
4-2
OLED77G6 Re-assembly Guide
(4-1) Put down [Sub PCB] and Fasten it with Screw 4EA, and then connect the connectors.
(4-2) Fasten the [Main PCB] Screw 6EA and Connect the indicated connectors.
