EXTERNAL CONTROL DEVICE SETUP
EXTERNAL CONTROL DEVICE SETUP
RS-232C Setup
Connect the RS-232C (serial port) input jack to
an external control device (such as a computer or
an A/V control system) to control the product’s
functions externally.
Connect the serial port of the control device to the
RS-232C jack on the product back panel.
I
N
1
CO
MP
O
NEN
T
IN
V
IDE
O
AU
DI
O
L
P
B
P
R
R
1
2
Y
V
IDE
O
AU
DI
O
R
L
/
M
O
N
O
AV
IN
R
EM
O
T
E
CO
NTR
O
L
IN
R
G
B IN
(
P
C
)
RS-232C IN
(CONTROL & SERVICE)
O
P
TI
C
AL
D
I
G
IT
A
L
AUDI
O
O
UT
ANTENNA
/
C
ABLE IN
AUDI
O
I
N
(
R
G
B/
DV
I
)
NOTE

RS-232C on this unit is intended to be used
with third party RS-232C control hardware
and software. The instructions below
are provided to help with programming
software or to test functionality using telenet
software. RS-232C connection cables are not
supplied with the product.
Type of connector;
D-Sub 9-Pin Male
1 5
6 9
RS-232C IN
(CONTROL & SERVICE)
No. Pin name
1 No connection
2 RXD (Receive data)
3 TXD (Transmit data)
4 DTR (DTE side ready)
5 GND
6 DSR (DCE side ready)
7 RTS (Ready to send)
8 CTS (Clear to send)
9 No Connection
