LG PQRCVCL0QW Engineering Product Data Book

3.2 Product Description
8 _ Wireless remote controller
Wireless remote controller
TM
HVAC Solution
3.1.1 Basic
• 2 inch mono display
• Temperature sensing
2. Specification
1. Feature
Power Supply 1.5 V (AAA Batteries 2EA)
Compatible product Air conditioner
Language English
3. Description
n Model name : PQWRHQ0FDB / PQWRCQ0FDB / PWLSSB21H / PWLSSB21C
TIME(3 s)
°C/°F(5 s)
153 mm
51 mm
26 mm
PQWRH(C)Q0FDB PWLSSB21H(C)
Appearance Part Descriptions Part Descriptions
Used to start or stop the plasma-purification function.
(This button can be used only for PQWRH(C)Q0FDB model)
Used to set or clear additional function.
Celsius/Fahrenheit Switching (If it press for 5 s)
Used to start or stop the air purification function.
Smart Indicator(Air quality) always on setting (If it press for 3 s)
Used to stop or start louver movement and set the
desired up/down airflow direction.
Used to set each vane angle.
Used to set the desired left/right(horizontal) airflow
direction.
Used to set airflow. Used to set the time of sleeping operation.
Used to turn on/off the unit. Used to set the time of starting operation.
Used to select the room temperature. Used to set the time of stopping operation.
Used to select the operation mode.
Used to set the timer. (If it is timer mode) Used to
adjust the brightness. (If it is not timer mode)
Used to check the room temperature. (If it is not timer mode)
/
Speed cooling(heating) operates super high
fan speed.
Used to set/clear the timer. Used to set the current time
(If it press for 3 s)
Used to set fan speed. Used to reset the remote controller.
h Depending on the model, some functions and the designs (ex. Icons and buttons, etc.) may be different.
