13
INSTALLATION
ENGLISH
the door down carefully from the cabinet
b
with the front side facing down to the floor.
• Remove the lower screw first. The door may fall
on to the floor due to its weight and the door can
be damaged.
2
Remove 8 screws on the hinge assembly
c
from the door.
• There are 6 screws on the front and 2 screws
on the side.
3
Remove the 3 screws from the door latch
assembly
d
which is fixed between the door
and the hinge assembly, and then remove the
screw which is fixed on the door hook.
4
Swap the position of the hinge assembly
c
and
the door latch assembly
d
and then tighten
the screws in reverse order.
• Tighten the screw in their proper position
referring from steps 2 to 4.
5
Remove the door catch
e
from the appliance
frame by removing 2 screws and then
assemble them on the opposite side.
6
Remove the 2 decorative screws from the
appliance frame and then assemble them on
opposite side.
To Next Page
