70UP7750PTZ 1562 971 362 907 59.9 29.1 28.4
75UP7750PTZ 1678 1027 362 964 59.9 32.1 31.4
Power requirement
The Analog Gender adapter can be purchased separately at Customer Service.
Do not look into the optical output ports,
looking at the laser beam may damage
your vision
Audio with ACP (Audio Copy Protection)
function may block digital audio output.
ARC (Audio Return Channel)
An external audio device that supports
SIMPLINK and ARC must be connected
using HDMI IN eARC/ARC port
When connected with a high-speed
HDMI cable, the external audio device
that supports ARC outputs SPDIF audio
without additional audio cable and supp-
orts the SIMPLINK function.
Some USB Hubs may not work, if a USB
device connected using a USB Hub is
not detected, connect it to the USB port
on the TV directly
Connect the external power source if
your USB is needed.
IN002043
