18
Reversible Inlet Grille
Hardware
Installation
Using the Reversible Inlet Grille (on some models)
Opening the front grille from the top of the unit:
Disassemble the inlet grille from the front grille. Separate
the hinged part by removing the screws using a flat-head
screwdriver.
Turn the inlet grille upside down and insert the hooks into
the lower holes of the front grille.
Insert the filter.
Opening the front grille from the bottom of the unit:
No change is required if you want to remove the filter from the
bottom side. (Factory configured)
To Next Page
