6
Connecting the Display
IMPORTANT
This picture depicts the general model of connection. Your monitor may differ from the
items shown in the picture.
Do not carry the product upside down holding only the stand base. The product may fall
and get damaged or cause injury.
4. Then fold the screw handle flat. 5. Once assembled take the monitor
up carefully and face the front side.
6. To disconnect the Stand Base from the Stand Body, unfold the screw handle
and turn it to the left.
3. Turn the screw to the right to fix the Stand Body to the Stand Base.
Screw
Turn the screw
by using the
screw handle.
