LG W2363D - Connecting with the PC;AV equipment

8
Connecting the Display
A
Connect DVI-D (Digital signal) Cable
Connect HDMI Cable (HDMI1, HDMI2)
1. Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.
2. Connect signal input cable and power cord in order, then tighten the
screw of the signal cable.
Connecting with the PC/ AV equipment
1 2
NOTE
This is a simplified representation of the rear view.
This rear view represents a general model; your display may differ from the view as shown.
Wall-outlet type
Varies according to model
DVI-D
Headphone/Earphone output
PC Speaker Out/Line out
AV equipment
(Set-Top Box, DVD,Video,
Video Game Console)
* HDMI is optimized on the AV equipment.
* Not supported PC.
3. Press the Power Button ( ) on the front panel to turn the power on.
B
