SPARE PARTS LIST - MIXERS WITH FIXED HEAD (10 ÷ 15 liters) SINGLE SPEED
MODELS: TMP10-230V-N, TMP15-230V-N
POS.
COD.
DESCRIPTION
TMP10
-230-N
TMP15
-230-N
FROM…
…TO
1
A96ZE00022
SAFETY GUARD IFM 10
✓
A96ZE00016
SAFETY GUARD IFM 15
✓
2
A96ZV00031
BOWL IFM 10
✓
A96ZV00033
BOWL IFM 15
✓
5
A96ZD00001
SNAP RING DIAM. 25 IF/IR
✓
✓
6
A89CK00012
BEARING 6204-2RS TFM 7÷10÷15
✓
✓
7
A96ZV00035
SUPPORT BOWL BASE IFM 7/10/15
✓
✓
8
A96ZN00061
BOWL CHAIN 06B/102 TFM 7÷10÷15
✓
✓
9
A96ZN00062
CHAIN WHEEL Z=50 06B IFM 7/10/15
✓
✓
10
A96ZI00034
BOWL BASE SHAFT IFM 7/10/15
✓
✓
11
A86ME24115
SCREW M8X35 TF÷TR
✓
✓
13
S63FS67002
SAFETY GUARD PIN IFM 7/10/15
✓
✓
14
A96ZE00012
CAM FOR SAFETY GUARD IF
✓
✓
15
A86ME32013
SCREW M8X10 TF÷TR
✓
✓
28
A96ZN00106
SUPPLY SCHUKO 90°
✓
✓
33
A96ZA00007
ROD BREAKING DOUGH IFM10
✓
A96ZA00008
ROD BREAKING DOUGH IFM 15
✓
34
A86ME24016
SCREW TE M6X25 ZN
✓
✓
39
A96ZB00011
SIDE SAFETY PANEL IFM 10
✓
A96ZB00010
SIDE SAFETY PANEL IFM 15
✓
41
A96ZF00011
STEEL FOOT M12 IF/IR
✓
✓
43
A96ZG00003
WHEEL WITH BRAKE M12 IF/IR
✓
✓
44
A96ZJ00020
MOTOR 230 V - 0,37 KW - 50 HZ - 71 - B14 - IFM 10/15
✓
A96ZJ00040
MOTOR 230 V - 0,45 KW - 50 HZ - 71 - B14 - IFM15
✓
45
A96ZC00028
UPPER PANEL IFM 10÷15
✓
✓
47
A96ZD00002
RING IN NYLON IF/IR
✓
✓
48
A86ME24119
SCREW M4X30 TF÷TR
✓
✓
54
A96ZG00004
WHEEL WITHOUT BRAKE M12 IF/IR
✓
✓
58
A96ZL00014
FLANGE FIXING REDUCTOR TFM 10÷15
✓
✓
61
A96ZL00019
GEAR BOX 71 B14 1/40 IFM 10/15
✓
✓
63
A96ZC00012
BACK PANEL IFM 10/15
✓
✓
65
A96ZN00114
BUTTON WHITE/BLACK START/STOP KLD-28A IFM 7/10/15-
RM 230V 50/60HZ
✓
✓
69
S14MT67005
SPIRAL CHAIN 06B/74 TFM 10
✓
S14MT67004
SPIRAL CHAIN 06B/72 TFM 15
✓
70
A96ZH00012
CHAIN PINION GEAR Z=23 06B IFM 7/10/15
✓
✓
71
A96ZI00035
BASE TRANSMISSION SHAFT UCFL 204 IFM 7/10/15
✓
✓
76
A86ME36006
KEY 6X6X30
✓
✓
81
A96ZH00008
CHAIN PINION GEAR Z=14 06B TF/TR 17/22
✓
✓
83
A96ZI00037
TRANSMISSION SHAFT IFM 10/15
✓
✓
84
A86ME36011
KEY 6X6X40 TFM 7÷10÷15
✓
✓
86
A96ZN00030
MICRO-SWITCH IF
✓
✓
96
A86ME25026
NUT M12 ZN
✓
✓
97
A96ZN00053
NYLON BLOCK BASE IF/IR
✓
✓
98
A86ME25018
NUT M5 ZN
✓
✓
99
A96ZN00052
TENSIONER BASE IF/IR
✓
✓
100
A86ME24122
SCREW TCEI M5X30 TF÷TR
✓
✓
