SPARE PARTS LIST - MIXERS WITH FIXED HEAD (22 liters) SINGLE AND TWO SPEEDS
MODELS: TMP22N – TMP22FKN
POS.
COD.
DESCRIPTION
TMP22N
TMP22FKN
FROM…
…TO
1
A96ZE00008
SAFETY GUARD IF/IR 22
✓
✓
2
A96ZV00016
BOWL IF/IR 22
✓
✓
5
A96ZD00001
SNAP RING DIAM. 25 IF/IR
✓
✓
6
A89CK00010
BEARING 6205-2RS TF÷TR
✓
✓
7
A96ZV00025
SUPPORT BOWL BASE IF/IR 17/22/33/42/53
✓
✓
8
S14MT67007
BOWL CHAIN 06B/126 IF÷IR 17÷22
✓
✓
9
A96ZR00004
CROWN Z=72 06B IF/IR 17/22
✓
✓
10
A96ZI00013
BOWL SUPPORT AXLE IF/IR 17/22/33/42/53
✓
✓
11
A86ME24115
SCREW M8X35 TF÷TR
✓
✓
12
A96ZE00013
GUARD RING IR
✓
✓
13
A96ZI00014
SAFETY GUARD PIN IF/IR 17/22
✓
✓
14
A96ZE00012
CAM FOR SAFETY GUARD IF
✓
✓
15
A86ME32013
SCREW M8X10 TF÷TR
✓
✓
21
A86ME24114
SCREW M8X30
✓
✓
25
A96ZS00004
SPIRAL IF/IR 17/22
✓
✓
28
A96ZN00026
SUPPLY WIRE IF/IR 17/22/33/42/53
✓
✓
33
A96ZA00005
DOUGH BREAKING ROD IF/IR 22
✓
✓
34
A86ME24117
SCREW M10X25 TF÷TR
✓
✓
39
A96ZB00012
SIDE SAFETY PANEL IF 22
✓
✓
41
A96ZF00011
STEEL FOOT M12 IF/IR
✓
✓
42
A96ZF00019
INSERT FOR PLASTIC FOOT IF/IR
✓
✓
43
A96ZG00003
WHEEL WITH BRAKE M12 IF/IR
✓
✓
44
A87MR56010
MOTOR 400 V - 0,75 KW - 50 HZ 80 B14 IF/IR17/22
+ IF/IR17/22 VS
✓
A96ZJ00043
MOTOR YS80B14 4-6 POLES/550-370W/1440-
960RPM 400V 50HZ - IF÷IR 17÷22 2V
✓
45
A96ZC00001
COVER IF/IR 17/22 (WHITE)
✓
✓
47
A96ZD00002
RING IN NYLON IF/IR
✓
✓
48
A86ME24119
SCREW M4X30 TF÷TR
✓
✓
52
A96ZF00007
AXIS COVER IR
✓
✓
54
A96ZG00004
WHEEL WITHOUT BRAKE M12 IF/IR
✓
✓
57
A96ZN00031
EMERGENCY STOP SWITCH IF/IR
✓
✓
58
A96ZL00010
REDUCTION GEAR FIXING RING IF/IR 17/22
✓
✓
60
A86ME32014
SCREW M8X40 TF÷TR
✓
✓
61
A96ZL00008
GEAR BOX CM050 80 B14 1/30 FLS IF/R 17/22
✓
A96ZL00023
GEAR BOX TCM050 I20/80 B14 IF÷IR 17÷22 2V
✓
62
A86ME24118
SCREW M5X10 TF÷TR
✓
✓
63
A96ZC00026
BACK PANEL TF 17/22 (WHITE)
✓
✓
65
A96ZN00038
MAIN SWITCH IF/IR 2V
✓
66
A96ZO00032
COMPLETE CONTROL BOX TMP-N (IF-1V-400V) –
vers 2024
✓
A96ZO00033
COMPLETE CONTROL BOX TMP-FK (IF-2V-400V) –
vers 2024
✓
67
A96ZN00089
COMPLETE BLACK/WHITE SWITCH IF/IR
22/33/42/53
✓
✓
68
A96ZM00004
TIMER IF/IR
✓
✓
69
S14MT67006
SPIRAL CHAIN 06B/82 IF÷IR 22
✓
✓
70
A96ZH00010
CHAIN PINION GEAR Z=29 06B IF/IR 17/22
✓
✓
71
A96ZI00024
TRANSMISSION SHAFT BASE UCF 204 IF 17/22 -
IR 17/22
✓
✓
