SPARE PARTS LIST– MIXERS WITH FIXED HEAD (33 ÷ 42 ÷ 53 liters) SINGLE AND TWO
SPEEDS
MODELS: TMP33N – TMP33FKN – TMP42N – TMP42FKN – TMP53N – TMP53FKN
POS.
COD.
DESCRIPTION
TMP
33N
TMP
33
FKN
TMP
42N
TMP
42
FKN
TMP
53N
TMP
53
FKN
FROM…
…TO
1
A96ZE00009
SAFETY GUARD IF/IR 33
✓
✓
A96ZE00010
SAFETY GUARD IF/IR 42
✓
✓
A96ZE00011
SAFETY GUARD IF/IR 53
✓
✓
2
A96ZV00017
BOWL IF/IR 33
✓
✓
A96ZV00018
BOWL IF/IR 42
✓
✓
A96ZV00019
BOWL IF/IR 53
✓
✓
5
A96ZD00001
SNAP RING DIAM. 25 IF/IR
✓
✓
✓
✓
✓
✓
6
A89CK00010
BEARING 6205-2RS TF÷TR
✓
✓
✓
✓
✓
✓
7
A96ZV00025
SUPPORT BOWL BASE IF/IR
17/22/33/42/53
✓
✓
✓
✓
✓
✓
8
S14MT67008
BOWL SPIRAL 06B/144 TF÷TR
33÷42÷53
✓
✓
✓
✓
✓
✓
9
A96ZR00005
CROWN Z=85 06B IF/IR 33/42/53
✓
✓
✓
✓
✓
✓
10
A96ZI00013
BOWL SUPPORT AXLE IF/IR
17/22/33/42/53
✓
✓
✓
✓
✓
✓
11
A86ME24115
SCREW M8X35 TF÷TR
✓
✓
✓
✓
✓
✓
12
A96ZE00013
GUARD RING IR
✓
✓
✓
✓
✓
✓
13
S63FS67001
SAFETY GUARD PIN TF/TR 33/42/53
✓
✓
✓
✓
✓
✓
14
A96ZE00012
CAM FOR SAFETY GUARD IF
✓
✓
✓
✓
✓
✓
15
A86ME32013
SCREW M8X10 TF÷TR
✓
✓
✓
✓
✓
✓
21
A86ME24114
SCREW M8X30
✓
✓
✓
✓
✓
✓
25
A96ZS00005
SPIRAL IF/IR 33/42
✓
✓
✓
✓
25
A96ZS00017
SPIRAL IF÷IR 53
✓
✓
27
A96ZN00025
WIRE CLIP IF/IR
✓
✓
✓
✓
✓
✓
28
A96ZN00026
SUPPLY WIRE IF/IR 17/22/33/42/53
✓
✓
✓
✓
✓
✓
33
A96ZA00002
ROD BREAKING DOUGH IF/IR 33
✓
✓
A96ZA00003
ROD BREAKING DOUGH IF/IR 42
✓
✓
A96ZA00004
ROD BREAKING DOUGH IF/IR 53
✓
✓
34
A86ME24117
SCREW M10X25 TF÷TR
✓
✓
✓
✓
✓
✓
39
A96ZB00007
SIDE SAFETY PANEL IF 33
✓
✓
A96ZB00005
SIDE SAFETY PANEL IF 42
✓
✓
A96ZB00013
SIDE SAFETY PANEL IF 53
✓
✓
41
A96ZF00011
STEEL FOOT M12 IF/IR
✓
✓
✓
✓
✓
✓
42
A96ZF00019
INSERT FOR PLASTIC FOOT IF/IR
✓
✓
✓
✓
✓
✓
43
A96ZG00003
WHEEL WITH BRAKE M12 IF/IR
✓
✓
✓
✓
✓
✓
44
A96ZJ00024
MOTOR 400 V -1,5 KW - 50 HZ 90 B14
IF/IR 33/42/53 + IF/IR 33/42/53VS
✓
✓
✓
A96ZJ00044
MOTOR YS90B14 4-6 POLES/1100-
800W/1440-960RPM 400V 50HZ - IF÷IR
33÷42÷53 2V
✓
✓
A96ZJ00054
MOTOR YS90B14 4-6 POLES/1,2-
0,9kW/1420-920RPM 400V 50Hz - IF÷IR
33 2V
✓
45
A96ZC00003
COVER IF/IR 33/42/53 (WHITE)
✓
✓
✓
✓
✓
✓
47
A96ZD00002
RING IN NYLON IF/IR
✓
✓
✓
✓
✓
✓
48
A86ME24119
SCREW M4X30 TF÷TR
✓
✓
✓
✓
✓
✓
52
A96ZF00007
AXIS COVER IR
✓
✓
✓
✓
✓
✓
54
A96ZG00004
WHEEL WITHOUT BRAKE M12 IF/IR
✓
✓
✓
✓
✓
✓
57
A96ZN00031
EMERGENCY STOP SWITCH IF/IR
✓
✓
✓
✓
✓
✓
