2-1. Machine Overview
12
1 Front Case 8 Rear Cover
2 Front Cover 9 Thickness Dial
3 Stacker 10 Interface Connector
4 Hopper guide 11 Inlet
5 Start/Stop Button (LEFT) + Power Button 12 Side Case R
6 Start/Stop + Print Button (RIGHT) 13 Side Case L
7 Touch LCD (GUI)
9
11
10
8
1
6
7
2
4
3
5
13
12
