Lifetime 80193 - Page 16

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
16
SEC
SEC
1.11
Turn the Table Cart right side up, and insert the four (4) End Caps (DBB)JOUPUIFGPVS'SPOUBOE3FBS7FSUJDBM4VQQPSUT
as shown.
SEC
1.10
Connect the Front and Rear Castors (DAK and DAJ) to the frame as shown using the required hardware. Completely tighten
these Screws.
DAJ
DBB
DBB
DBB
DBB
DAJ
DAK
DAK
DAD (x16)
5/32”
1
Note: The Table Cart will hold eight (8) 5’ or 6’ round
tables or approximately twelve (12) rectangular tables.
!
