LEGO ASSEMBLY SQUARE 10255 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 63
40 41
Legend
DISCONNECT
CONNECT /
RECONNECT
TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
White Strip Light
Plate 1x6 (Any Colour)
Wireless Power Connector
(Plate Side)
