DEUTSCH
Anschlüsse und Bedienelemente:
Nr.
Bezeichnung
Nr.
Bezeichnung
1
9 x RGB Innere LEDs
7
Tragegriffe
2
33 x RGB Äußere LEDs
8
Stromeingang (PowerCon)
3
Nebeldüse
9
DMX Eingang (3-pol)
4
Fluidbehälter mit Verschluss
10
DMX-Ausgang (3-pol)
5
Ein-/Aus-Schalter
11
Lüfter
6
Bedienelemente (Display/Tasten)
12
Ringöse z.B. für Safety
