Protected componentsFuse amp ratingFuse
Alternator sensor
10A
1
F28
Rain sensor
15A
1
F29
Rear wiper
Washer pump relay coil
Left-hand headlamp
20A
1
F30
Right-hand headlamp
20A
1
F31
Vehicle power 1 (powertrain control module)
15A
1
F32
Vehicle power 2 (canister vent solenoid, universal exhausted
gas oxygen sensor, variable camshaft timing, catalyst monitor
sensor, canister purge solenoid)
15A
1
F33
Vehicle power 3 (A/C clutch control relay coil, variable A/C
compressor, fan control relay coil, engine charge air bypass
valve solenoid, active grill shutters)
15A
1
F34
Vehicle power 4 (ignition coils)
15A
1
F35
Not used—F36
Not used—F37
266
Fuses
