Protected componentsFuse amp ratingFuse
Not used.—F47
Not used.—F48
1
Mini fuse.
2
J-case fuse.
Circuits switchedRelay
Run start.R1
Horn.R2
Fuel pump.R3
Rear window washer pump.R4
Cooling fan relay 3 (with trailer tow).R5
Windshield wipers.R6
Cooling fan relay 1 (without trailer tow).R7
Cooling fan relay 5 (with trailer tow).
Starter.R8
Not used.R9
271
MKC (TME), enUSA, First Printing
Fuses
