Parts list
Item no. Description Part no. Quantity Item no. Description Part no. Quantity
1 Clip 278356 1 24 Nozzle None 1
2 Screw 278356 1 25 Ball valve 278342 1
3 Valve core
5)
278569 1 26 Air connector
4 O-ring 0.37 x 0.078 in. (9,5 x 2 mm)
1), 5)
None 1 27 Muffler 278344 1
5 Valve body
5)
278569 1 28 O-ring 0.15 x 0.31 in. (4 x 8 mm)
1)
6 Wand holder 278357 1 29 Valve 278345 1
7 Wand 5 mm dia, (700 mm) copper 278363 1 30 O-ring 1.65 x 1.8 in. (42 x 47 mm)
1)or 8)
None 1
Wand 6 mm dia, (700 mm) copper 278364 1 31 Retaining ring
8)
None 1
Wand 5 mm dia, (700 mm) plastic 278365 1 32 Ball
8)
None
Wand 6 mm dia, (700 mm) plastic 278366 1
Wand 8 mm dia, (700 mm) plastic 278367 1 33 O-Ring 0.35 x 0.55 in. (9 x 14 mm)
1) or 8)
None 1
Wand 7 mm dia, (1 000 mm) plastic 278368 1 34 Seat
8)
None
35 Tube
8)
None 1
BMW adapter 278369 1 36 Tool tray 278346 1
VW adapter 278370 1 37 Relief valve, 14 psi (1 bar) 278347 1
8 O-ring
1)
kit 38 Y adapter 278341 1
0.39 x 0.10 in. (9,9 x 2,6 mm) BMW 2 39 Ta n k None 1
0.26 x 0.07 in. (6.7 x 1,8 mm) VW 1 40 Extension funnel 278372 1
9 Plug
2)
None 1 41 Screen 278373 1
10 O-ring 0.23 x 0.35 in. (6 x 10 mm)
1), 2)
None 2 42 Funnel and adapter 278374 1
11 Hose 278340 1 43 Swivel assembly 278375 1
12 Chain
2)
None 1 44 Ball valve
3
/4 in. NPTF 278376 1
13 Ball valve
1
/4 in. NPTF 278360 1 45 Extension tube 278380 1
14 Adapter 90°
1
/4 in. BSP (internal)
x
1
/4 in. NPT (external)
278339 1 46 Drain hose assembly 278993 1
15 Handle with two screws
7)
278362 1 47 Wheel and screw
3)
278352 2
16 Connector
2)
278359 1 48 Caster kit
4)
278351 2
17 O-ring 0.51 x 0.62 in. (13 x 16 mm)
1), 2)
None 2 49 Level gauge 278350 2
18 Vacuum gauge 278338 1 50 Elbow 278353 2
19 Adapter 90°
1
/4 in. BSP 278379 1 51 Adapter 278353 2
20 Adapter, Y 278377 1 52 Adapter 278354 1
21 Ball valve
1
/4 in. NPTF 278342 1 53 Ball valve
1
/2 in. NPTF 278354 1
22 Collar 278378 1 54 Hose and nozzle 278348* 1
23 Adapter 276343 1 55 Plug
6)
278349 1
56 O-ring
6) or 1)
None 2
Table 4
1)
Seal kit 278337
2)
Adapter and plug kit for evacutaor hose 278359
3)
Wheel kit 278352
4)
Caster kit 278351
5)
Inlet valve assembly 278569
6)
Plug and chain kit for discharge hose 278349
7)
Handle kit 278362 (handle and the two screws)
8)
Vacuum body kit 278343
*
Indicates change.
6
