Replacing HID headlamp bulbs (if equipped)
The low beam headlamps on your vehicle use a “high intensity discharge”
source. These lamps operate at a high voltage. When the bulb is burned
out, the bulb and starter capsule assembly must be replaced by your
authorized dealer.
Replacing front parking lamp/turn signal bulbs
1. Make sure the headlamp switch is in the off position, then open the
hood..
2. At the wheel well, remove the
fasteners from the splash shield,
then pull the splash shield back to
gain access to the bulbs.
3. Rotate the bulb socket
counterclockwise and remove from
the lamp assembly.
4. Carefully pull the bulb out of the
socket.
5. Reverse the procedure to install the new bulb.
Lights
55
2012 MKX (mkx)
Owners Guide, 1st Printing
USA (fus)
