Section 7
Page 9
Service Training
RP01 / Chapter 1
115 804 2401.1000
WARNING: Manual handling risk. The pump motor is heavy, do not attempt to remove the
motor without the correct lifting equipment.
7.6.1 HYDRAULIC PUMP AND MOTOR RE-FITTING
- To re-fit the pump and motor into the chassis, reverse the removal procedure.
WARNING: Manual handling risk. The pump motor is heavy, do not attempt to replace the
motor without the correct lifting equipment.
CAUTION: The pump operates by suction, due to the outlet flow from the hydraulic tank
being located higher than the pump. Therefore, it will be necessary to prime the power
steering pump by dismantling the suction hose at the tank end, and pouring clean
hydraulic into the suction hose.
Failure to do this will cause the pump to run dry and resulting in premature pump failure.
