Line 6 Helix Troubleshooting Instructions

Line 6 Customer Service
Helix Floor Expression Pedal
Troubleshooting Instructions Rev A
Document 90-20-0505
Line 6 Page 3 of 13 5/9/2017
The Helix product contains Hazardous Voltages that can cause serious injury or
death.
Do not attempt to troubleshoot the expression pedal until you have read and fully
understood these instructions.
Before troubleshooting the expression pedal, ensure the following is complete:
 Helix power cord is disconnected from the Helix.
 Power switch is set to “OFF”.
 There are no liquids near your work area.

Line 6 Helix Specifications

General

Type	Multi-Effects Processor
Inputs	1 x XLR (mic)
Outputs	1 x 1/4" (headphones)
Display	6.2" LCD
Footswitches	12
Connectivity	MIDI In/Out, USB, S/PDIF
Power Supply	Internal power supply (100-240V)
Amp Modeling	Yes
Software	Helix Edit
Expression Pedal	Built-in
USB	Yes
Presets	1024
Looper	Yes (up to 60 seconds)
