Line 6 POD X3 User Manual

50-02-0079
PCBA MAIN POD X3 TNG BEAN P10-1
Part Number Description Qty. Per Reference Designator(s)
01-12-0101
RES CARBON FILM 100R 1/4W 5% TH 1 R148
01-21-015R
RES METAL OXIDE 0.15R 1W 5% TH incorrect PN.. use 01-21-0R15 1 R149
01-22-0160
RES METAL OXIDE 16R 2W 5% TH 1 R33
01-24-0000
RES 0R 1% 0805 2 L5,L16
01-24-10R0
RES 10.0R 1% 0805 3 R7,R50,R112
01-24-1300
RES 130R 1% 0805 8 R51,R52,R54,R55,R75,R77,R78,R79
01-24-1331
RES 1.33K 1% 0805 4 R1-2,R19,R21
01-24-1502
RES 15.0K 1% 0805 1 R145
01-24-15R0
RES 15R 1% 0805 2 R86,R119
01-24-1653
RES 165K 1% 0805 1 R146
01-24-2002
RES 20.0K 1% 0805 16 R9,R10,R37,R40,R41,R44,R61,R62,R63,R64,R70,R83,R90,R91,R127,R128
01-24-2210
RES 221R 1% 0805 1 R147
01-24-22R1
RES 22.1R 1% 0805 2 R140,R141
01-24-30R1
RES 30.1R 1% 0805 3 R60,R80,R81
01-24-3481
RES 3.48K 1% 0805 1 R82
01-24-4752
RES 47.5K 1% 0805 1 R92
01-24-47R5
RES 47.5R 1% 0805 13 R47,R66,R69,R84,R85,R87,R89,R103,R104,R105,R118,R120,R121
01-24-4870
RES 487R 1% 0805 1 R30
01-24-5R11
RES 5.11R 1% 0805 1 R113
01-24-8871
RES 8.87K 1% 0805 4 R17,R18,R45,R46
01-24-88R7
RES 88.7R 1% 0805 1 R31
01-25-0000
RES 0R 1% 0603 2 R130,R136
01-25-1001
RES 1.00K 1% 0603 6 R35-36,R126,R139,R155-156
01-25-1002
RES 10.0K 1% 0603 15 R6,R26,R34,R59,R93,R97,R114,123,R125,R129,R134,R138,R151,R171,R172
01-25-1004
RES 1.00M 1% 0603 2 R5,R142
01-25-10R0
RES 10.0R 1% 0603 3 R22,R133,R157
01-25-1400
RES 140R 1% 0603 2 R153,R253
01-25-1501
RES 1.50K 1% 0603 4 R12,R14,R20,R154
01-25-1502
RES 15.0K 1% 0603 1 R124
01-25-1821
RES 1.82K 1% 0603 1 R122
01-25-2001
RES 2.00K 1% 0603 14 R15,R16,R25,R28,R29,R38,R39,R42,R43,R58,R67,R68,R115,R116
01-25-4022
RES 40.2K 1% 0603 1 R94
01-25-4751
RES 4.75K 1% 0603 17 R3,R4,R8,R53,R56,R57,R71,R72,
01-25-4990
RES 499R 1% 0603 4
R73 R74 R95 R96 R111 R144 R152 R159 R160
R11,R13,R76,R143
01-25-5901
RES 5.90K 1% 0603 1 R137
01-25-5R11
RES 5.11R 1% 0603 1 R158
01-48-0103
POT MONO 10KB LINEAR TAPER 25 mm D-SHAFT 8 R23-24,R27,R32,R48,R65,R88,R117

Line 6 POD X3 Specifications

General

Type	Multi-Effects Processor
Amp Models	78
Effects Models	98
Display	LCD
Technology	Digital
Inputs	1 x 1/4" Guitar, 1 x XLR Mic, 1 x 1/4" Aux
Outputs	1 x XLR
MIDI	In/Out
USB	Yes
Power Supply	9V AC adapter (included)
