Line 6 POD X3 User Manual

C130 D131 D132 C138 C139 C143 C144 C145 C146 C148 C149 C150 C152
50-02-0079
PCBA MAIN POD X3 TNG BEAN P10-1
Part Number Description Qty. Per Reference Designator(s)
01-48-9106
POT SINGLE 10KC Log Taper Right Angle 25 mm Shaft 1 R162
03-10-0331
CAP ELEC 330uF 10V 20% RADIAL 6.3/11.2/5 1 C170
03-10-1107
CAP ELEC 100uF 6.3V 20% RADIAL5/11/5 3 C110,C126,C168
03-10-1108
CAP ELEC 1000uF 10V 20% RADIAL 10/12.5/5 1 C195
03-12-0107
CAP ELEC 100uF 16V 20% RADIAL 6.3/11/5 4 C78,C212,C213,C238
03-12-0228
CAP ELEC 2200uF 16V 20% RADIAL12.5/20/5 2 C178,C201
03-12-0476
CAP ELEC 47uF 16V 20% RADIAL 6.3/11.2/5 2 C200,C247
03-12-0688
CAP ELEC 6800uF 16V 20% RADIAL18/35.5/7.5 1 C141
03-13-0107
CAP ELEC 100uF 16V 20% 105C LowZ 0.350R RADIAL 6.3/11.2/5 3 C127,C153,C154
03-14-0108
CAP ELEC 1000uF 25V 20% RADIAL 10/20/5 0 C142,C159
03-15-1477
CAP ELEC 470uF 25V 20% 105C LowZ 0.1R RADIAL 10/20/5 1 C191
03-16-0108
CAP ELEC 1000uF 35V 20% RADIAL12.5/20/5 1 C157
03-18-0105
CAP ELEC 1uF 50V 20% RADIAL 5/11/5 6 C179,C186,C196,C242,D243,C246
03-18-0106
CAP ELEC 10uF 50V 20% RADIAL 5/11/5 10 C115,C155,C171,C174,C180,C181,C184,C187,C189,C217
03-18-0225
CAP ELEC 2.2uF 50V 20% RADIAL 5/11/5 2 C233,C234
03-19-0107
CAP ELEC 100uF 50V 20% 105C LowZ 0.2R RADIAL 8/20/5 1 C197
03-36-0224
CAP ESTR 0.22uF 50V 5% TH 11/6/11.5/7.5 1 C98
03-45-0473
CAP 47nF 16V 20% 1206 FILM 1 C210
03-50-0120
CAP NPO 12pF 50V 5% 0805 2 C91,C92
03-50-0272
CAP NPO 2.7nF 50V 5% 0805 2 C99,C108
03-50-0391
CAP NPO 390pF 50v 5% 0805 4 C101,C102,C105,C106
03-50-0472
CAP NPO 4.7nF 25V 5% 0805 2 C133,C136
03-50-0561
CAP NPO 560pF 50v 5% 0805 2 C304,C305
03-52-0222
CAP X7R 2.2nF 50V 10% 0805 8 C1,C2,C9,C10,C11,C12,C16,C17
03-52-0331
CAP X7R 330pF 50V 10% 0805 1 C216
03-52-0473
CAP X7R 47nF 50V 10% 0805 10 C77,C109,C134,C137,C156,C160,C190,C192,C194,C202
03-56-0100
CAP NPO 10pF 50V 5% 0603 2 C218,C219
03-56-0101
CAP NPO 100pF 50V 5% 0603 8 C75,C100,C107,C117,C198,C199,C204,C208
03-56-0102
CAP NPO 1nF 50V 5% 0603 6 C76,C135,C158,C183,C185,C230
03-56-0470
CAP NPO 47pF 50V 5% 0603 1 C214
03-58-0102
CAP X7R 1nF 50V 10% 0603 26 C4,C5,C8,C29,C35,C37,C40,C43,C44,C45,C47,C48,C51,C56,C58,C59,C60,C61
,C65,C66,
03-58-0103
CAP X7R 10nF 50V 10% 0603 6 C6,C20,C31,C93,C97,C124
03-58-0104
CAP X7R 0.1uF 25V 10% 0603 27 C161,C162,C163,C164,C165,C167,C169,C176,C177,C182,C188,C193,C203,C2
05,C206,C207,C209,C211,C215,C235,C235,C236,C237,C239,C244,C245,C306,
C307,C3,C7,C18,C19,C21,C22,C23,C24,C25,C26,C27,C28,C30,C32C,C33,C34,
C36,C38,C39,C41,C42,C46,C49,C50,C52,C53,C54,C55,C57,C62,C63,C64,C67,
C68,C69,C70,C71,C72,C73,C74,C79,C80,C81,C82,C83,C84,C85,C86,C87,C89,
C94,C95,C103,C104,C111,C112,C113,C114,C116,C119,C120,D121,D122,D123,

Line 6 POD X3 Specifications

General

Type	Multi-Effects Processor
Amp Models	78
Effects Models	98
Display	LCD
Technology	Digital
Inputs	1 x 1/4" Guitar, 1 x XLR Mic, 1 x 1/4" Aux
Outputs	1 x XLR
MIDI	In/Out
USB	Yes
Power Supply	9V AC adapter (included)
